- Support USB3.0 Specification
- Integrated 10/100/1000M transceiver
- Support Ethernet cables Crossover Detection and Auto-Correction
- Support power down / link down power saving
- USB-C female port supports PD3.0 (100W)
- Support Microsoft’s AOAC (Always On Always Connected) Mode
- Compatible with all USB-C devices
- Support Windows 10 above, MacOS 10.12 above
Specification
| Warranty Information | |
|---|---|
| Warranty | 1 Year |
| Hardware | |
| Bus Type | USB-C |
| Chipset ID | RTL8153 + VL103 |
| Industry Standards | IEEE 802.3, 802.3u and 802.3ab |
| Interface | RJ45 (Gigabit Ethernet) , USB-C PD3.0 |
| Ports | 2 |
| Performance | |
| Auto MDIX | Yes |
| Compatible Networks | 10/100/1000 Mbps |
| Full Duplex Support | Yes |
| Maximum Cable Length | 0.6 in [1.5 cm] |
| Maximum Data Transfer Rate | 5Gbps |
| Type and Rate | USB 3.0 – 5 Gbit/s |
| Connector(s) | |
| Connector Type(s) | 1 – USB Type-C (24 pin) USB 3.0 Male |
| External Ports | RJ-45 Female + USB-C PD3.0 |
| Software | |
| OS Compatibility | Windows 10, 11 MacOS 10.12 above |
| Special Notes / Requirements | |
| System and Cable Requirements | Available USB Type-C port |
| Power | |
| Power Source | USB-Powered |
| Environmental | |
| Humidity | 20% ~ 90% RH |
| Operating Temperature | 0°C to 70°C (32°F to 158°F) |
| Storage Temperature | -55°C to 125°C (-67°F to 257°F) |
| Physical Characteristics | |
| Color | Black |
| Form Factor | Attached Cable |
| What’s in the Box | |
| Included in Package | 1 – VL-RJ45-CP |
